Alpha-Omega Power Technologies (AOPT) specializes in high voltage pulsed power design and manufacturing. AOPT has industrial proven design ranging in power from a few hundred watts up to 50 kilowatts. We can design and build a complete turn-key system to meet your requirements. Please Contact Us to discuss your requirements.

Pulse Generators

Pulsed Power

Optical Isolation COM Box

SHI-ISO-001









Pulsed Power

Pockel Cell Driver

PCD-25 Pockels Cell Driver

Voltage: 25 kV
Current: 500 A
Width: 50 ns
Pulse Rate: 250 Hz

Options: TCP/IP and Touch Panel
Pulse Power: < 500 W
Rise Time: < 50 ns
Pulsed Power

Spark Gap Trigger Unit

TRG-SPK-2014

Voltage: 100 kV
Current: 4000 A
Width: FIXED
Pulse Rate: SS

Options: TCP/IP and Touch Panel
Pulse Power: 250 W
Rise Time: 10 ns
Pulsed Power

Pulsed Reset Supply

LTD TRIGGER UNIT

Voltage: 3.5 kV
Current: 1,000 A
Width: FIXED
Pulse Rate: SS

Options: TCP/IP and Touch Panel
Pulse Power: 250 W
Rise Time: 75 us
Pulsed Power

Bench Top Pulse Unit

SHI-2009-250-080

Voltage: 800 V
Current: 250 A
Width: 1 - 400 us
Pulse Rate: 1 Hz

Options: GPIB or TCP/IP or USB
Pulse Power: 80 W
Rise Time: 200 ns
Pulsed Power

Bench Top Pulse Unit

SHI-2003-150-800

Voltage: 4.5 kV
Current: 150 A
Width: 1 - 10 us
Pulse Rate: 100 Hz

Options: GPIB or TCP/IP or USB
Pulse Power: 800 W
Rise Time: 400 ns
Pulsed Power

Bench Top Pulse Unit

SHI-2003-150-040

Voltage: 4.5 kV
Current: 150 A
Width: 1 - 12 us
Pulse Rate: 5 Hz

Options: GPIB or TCP/IP or USB
Pulse Power: 40 W
Rise Time: 400 ns
Pulsed Power

Bench Top Pulse Unit

SHI-2003-350-190

Voltage: 4.5 kV
Current: 350 A
Width: 1 - 12 us
Pulse Rate: 10 Hz

Options: GPIB or TCP/IP or USB
Pulse Power: 190 W
Rise Time: 400 ns
Pulsed Power

Optical Trigger Pair

AOPT-FO-001









Pulsed Power

Timing System

AOPT-TMS-B



Width: 250 ns

Pulse Notes:
Options: USB


Pulsed Power

HV Pulse Board

High Current Pulse Board

Voltage: 800 V
Current: 100 A
Width: 10 ns - 1 us
Pulse Rate: 100 kHz



Rise Time: < 10 ns
Pulsed Power

Diode Tester

DTU-2018


Current: 1,250 A


Pulse Notes:


Rise Time: 40 ns
Pulsed Power

TWT Modulator PS

PPS-2016-400-2K-2

Voltage: 40 kV
Current: .1 A
Width: 1 us - 3 ms
Pulse Rate: 120 Hz
Pulse Notes:
Options: TCP/IP and Touch Panel
Pulse Power: 2 kW
Rise Time: <1 us
Pulsed Power

High Voltage Pulse Unit

AOPT-HVPG-150K

Voltage: 150 kV
Current: 20 A
Width: 1 - 50 us
Pulse Rate: 1 Hz

Options: TCP/IP and Touch Panel
Pulse Power: 2500
Rise Time: <1 us
Pulsed Power

Ignitron Trigger Unit

AOPT-IGTRG

Voltage: 3 kV
Current: 2000 A
Width: 50 us
Pulse Rate: 0.25 Hz



Rise Time: 20 us

Megaherts Burst Unit

FPG-2007-A

Voltage: 800 V
Current: 16 A
Width: 50 ns - 1 us
Pulse Rate: 1 - 1 MHz
Pulse Notes:
Options: GPIB or TCP/IP or USB
Pulse Power: 100 W
Rise Time: 10 ns

Capacitor Banks

Pulsed Power

MegaJoule Capacitor Banks

AOPT-MJ-50K

Voltage: 30 kV
Current: 100 kA

Pulse Rate: SS





HV Switching

Pulsed Power

Stackable Switch Stack

AOPT-SWS-30K

Voltage: 30 kV
Current: 200 A
